| Brand Name: | SONGO |
| MOQ: | 2 pieces |
| Price: | CN¥140/pieces 2-29 pieces |
| Payment Terms: | L/C,D/P,D/A,T/T,Western Union,MoneyGram |
| Supply Ability: | 30000 Piece/Pieces per Month |
Benefits Of Miniaturized motorized 2 way Ball Valve:
It is widely used in building automatic control systems such as heating, ventilation, air conditioning and refrigeration. It can adjust the flow of fluid in the system pipeline by controlling the opening or closing of valves and the opening (analog) of valves, in order to obtain a comfortablel greenhouse environment and achieve the effect of saving energy.
Features Of Miniaturized motorized 2 way Ball Valve :
1). Equal percentile traffic characteristics
2). Valve body brass forging,600KPA closed differential pressure, PN16 PN20 valve body pressure
3). Equipped with manual mechanism, easy to adjust and easy to maintain
4). The built-in micro switch is specifically in place with power-off function, and the service life of the motor is longer.
5). The actuator is dismantled and easy to install. It can be installed after the equipment and pipeline are installed.
6). The closing pressure difference is large, the closing is strict, and the valve is flexibly opened, which can effectively prevent water hammer
Driver parameters:
| Parameter | Specification |
| Motor type | Synchronous machine |
| Power cord length | 300mm |
| Action Time | 25 seconds |
| Torque | 4N.m |
| Close differential pressure | ≤0.6Mpa |
| Nominal pressure | PN16~PN20 |
| Medium temperature | 5~95°C |
| Watt consumption | 50/60Hz 6W(Only when the valve is open) |
| Applicable media | Cold, hot water or 50% ethanol solution |
| Electrical specifications | 24VAC/110VAC/220VAC |
| Operating angle | 0°/90° |
Dimension Drawing:
Valve body parameters:
| Product specifications | Caliber | H (mm) | L (mm) | L1 (mm) | K Value (M³/H) | Net Weight (KG) |
| Two-way | DN15(1/2) | 110 | 54 | 11 | 0.48 | |
| DN20(3/4) | 114 | 62 | 20 | 0.57 | ||
| DN25(1) | 120 | 65 | 60 | 0.62 | ||
| DN32(1-1/4) | 125 | 75 | 80 | 0.89 | ||
| Three-way | DN15(1/2) | 108 | 54 | 43 | 11 | 0.55 |
| DN20(3/4) | 115 | 70 | 56 | 20 | 0.62 | |
| DN25(1) | 120 | 83 | 63 | 60 | 0.85 |
Wiring diagram:
