| Brand Name: | SONGO |
| MOQ: | 2 pieces |
| Price: | CN¥1400/pieces 2-29 pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 30000 Piece/Pieces per Month |
SONGO Groove Electric Gate Valve:
The electric groove gate valve is a type of valve that combines the groove-type pipe connection system with the gate valve structure and is equipped with an electric actuator for remote automated control. It integrates the advantages of rapid installation, reliable cutting, and intelligent control, and is widely used in modern fire protection, water supply and drainage, air conditioning, industrial pipelines, and other systems that require automated fluid control.
Features Of QT450 groove Motorized gate valve :
1). The groove connection is connected to the pipeline through a dedicated rubber gasket and clamp, and the installation is extremely quick. Significantly reduces labor and time costs. Particularly suitable for sites with limited space or those requiring rapid renovation.
2). When the gate valve is fully open, the gate plate rises completely, creating a direct passage with minimal resistance, almost zero. This effectively reduces system energy consumption.
3). The shut-off sealing performance of the gate valve is excellent, with a very low leakage rate.
4).It can achieve remote, centralized or programmed control, with rapid response and precise control.
SONGO Electric Groove Gate Valve Parameter:
| NO. | Name | Material |
| 1 | Valve Body | Cast Iron(QT450) |
| 2 | Valve Plate | Cast Iron(QT450)+EPDM |
| 3 | Valve Cover | Cast Iron(QT450) |
| 4 | Seal Ring | EPDM |
| 5 | Bracket | Carbon Steel |
| 6 | Stem | Carbon Steel/2Cr13 |
| 7 | Electric Actuator | |
Direct Acting piston steam Solenoid Valve of Structure Parameters:
| DN | L | D | C | A | B | f | H |
| 50 | 120 | 60.3 | 57.15 | 15.88 | 7.93 | 1.58 | 325 |
| 65 | 145 | 76.1 | 72.26 | 15.88 | 7.93 | 1.98 | 380 |
| 80 | 157 | 88.9 | 84.94 | 15.88 | 7.93 | 1.98 | 425 |
| 100 | 178 | 114.3 | 110.08 | 15.88 | 9.53 | 2.11 | 455 |
| 125 | 200 | 139.7 | 135.48 | 15.88 | 9.53 | 2.11 | 480 |
| 150 | 226 | 165.1 | 160.9 | 15.88 | 9.53 | 2.16 | 500 |
| 200 | 277 | 219.1 | 214.4 | 19.05 | 11.1 | 2.34 | 620 |
| 250 | 311 | 273 | 268.28 | 19.05 | 12.7 | 2.39 | 750 |
| 300 | 315 | 323.9 | 318.29 | 19.05 | 12.7 | 2.77 | 880 |
