Stainless Steel Wafer Pneumatic Actuator Valve Lug Type Single Acting EPDM

Stainless Steel Wafer Pneumatic Actuator Valve Lug Type Single Acting EPDM

Brand Name:	SONGO
MOQ:	2 PCS
Price:	CN¥240.57/pieces 1-29 pieces
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	5000-10,000Pieces/Month

Detail Information

Product Description

Detail Information

Certification:

CE , API , SIL , ISO 9001 , TS , RoHS , EAC

Body Material:

Ductile Cast Iron , A216 WCB , A351 CF8 , A351 CF8M , A351 CF3M , Duplex S.S. 2507 , Duplex S.S. 2205 , Super S.S.-1.4529 , B148-C95400 , B148-C95800

Disc Material:

Ductile Iron Ni Plated , Ductile Iron Nylon Coated , CF8M , A351 CF8

Seat Material:

PTFE , BUNA-N , EPDM , FKM

Pressure:

ASME Class 150 , 300LB , DIN PN16 , JIS 10K

Size Range:

DN25~DN1000 (1"~40")

Temperature:

-23 ~ 200℃

End Connection:

Lug , Wafer , Flange

Matching Flange Standard:

HG/T 20592 , GB/T9113 , JB/T78-79 , EN 1092-1 , ASME B16.5 , ASME B16.47 , DIN 2543-2545 , JIS B2220

Mode Of Pneumatic Actuator Operation:

Single Acting(Spring Return) , Double Acting

Actuator Accessaries Options:

Limit Switch Box , Proximity Switch , Positioner , Solenoid Valve , Air Filter Regulator , Declutchable Gear Box

Other Operation Options:

Handlever , Worm Gear , Electric Actuator , Hydraulic Actuator

Applicable Medium:

Water , Liquid , Gas , Oil , Powder , Steam , Acid And Alkali Corrosive Medium

Brand Name:

SONGO

Warranty:

2 Years

Customized Support:

OEM , ODM

Leakage Class:

Zero Leakage

Packaging Details:

Export Wooden Cases , Export Wooden Pallets , Carton Boxes

Highlight:

Wafer Pneumatic Actuator Valve

Lug Type Pneumatic Actuator Valve

EPDM Single Acting Actuator Valve

Product Description

Descriptions And Features Of Stainless Steel EPDM Lug Pneumatic Butterfly Valve:

Stainless steel wafer pneumatic butterfly valves are corrosion-resistant and reliable in control. Stainless steel 304 wafer pneumatic butterfly valves can be used in chemical process industry, water treatment, microelectronics, measurement and control, shipbuilding. Most applications such as Food & beverage. Stainless steel wafer pneumatic EPDM butterfly valves is suitable for wafer type and lug type. They are compact, diverse and reliable. The stainless steel Lug pneumatic butterfly valve adopts a modular design, allowing individual system components to be replaced at any time. The actuator of stainless steel lug EPDM pneumatic butterfly valves with Single Action ( Spring Return / Fail-Safe ) Option No.1 Is Air-To-Open / Fail Close / FC / Spring-To-Close / Normally Closed / NC , Option No.2 Is Air-To-Close / Fail Open / FO / Spring-To-Open / Normally Open / NO. Double Action Is Air-To-Open And Air-To-Close.

Design Features Of SONGO Pneumatic Actuator:

01) Actuator Body : Corrosion protected aluminium extruded body.
02) Movement Option : 2 Position 90° Turn , 2 Position 120° Turn , 2 Position 180° Turn , 3 Position 90° Turn , 3 Position 180° Turn.
03) Indicator : It is standard on all actuators.
04) Caps : Aluminium extruded caps provide maximum resistance against corrosion, caps are suitable for single and double acting actuators.
05) Stroke Adjustment : Permit adjustment of ± 5% in both directions.
06) Springs : Cartridge design and corrosion resistant springs.
07) Piston Bearing O-rings : Long lasting
08) Nuts and Bolts : Stainless steel and high resistance for corrosion.
09) Actuator Pistons : Aluminium injections. High quality o-rings and against corrosion.
10) Connections : Limit Switch Box , Proximity Switch , P/P Pneumatic Positioner ( Control Input Signal Is 0.20-1.03 Bar or 3-15 PSI ) , E/P Electro Pneumatic Positioner ( Control Input Signal Is 4-20mA ) , 3/2 Way Namur Solenoid Valve , 5/2 Way Namur Solenoid Valve , Air Filter Regulator , Declutchable Gear Box , Ball Valve , Butterfly Valve , Plug Valve
11) Cycle Life : 1,000,000 Operations

12) Temperature Range : High Temperature (FKM) -15°C~+150°C / +5°F~+302°F , Standard Temperature (NBR) -20°C~+80°C / -4°F~+176°F , Low Temperature (L-NBR) -40°C~+65°C / -40°F~+149°F

13) Air Supply Pressure : Minimum supply pressure is 2.41 Bar or 35 PSI , Maximum supply pressure is 10.34 Bar or 150 PSI

14) Actuator Operation Mode :

• Single Action ( Spring Return / Fail-Safe )
Option No.1: Air-To-Open / Fail Close / FC / Spring-To-Close / Normally Closed / NC
Option No.2: Air-To-Close / Fail Open / FO / Spring-To-Open / Normally Open / NO

• Double Action
Air-To-Open And Air-To-Close

Part Material Of Stainless Steel EPDM Lined Lug Pneumatic Butterfly Valve:

Connect Type	L/T Lug Type
Working Pressure	1.6Mpa
Brand	SONGO
Size	DN50-DN500
Temperature	-23℃~+200℃
Medium	Fresh water,sewage, sea water, air, steam, food, medicine, oils, acids, etc.
Body	Cast iron, ductile casting iron, stainless steel
Disc	Ductile casting iron, stainless steel
Stem	Stainless steel, carbon steel
Seat	NBR, EPDM, PTFE
Operated	Pneumatic actuated
Actuator parts	Solenoid valve, limit switch, positioner, FRL
Actuator type	Double action, spring return

Structure Dimension Drawing Of Pneumatic Operated SS304 EPDM Lug Butterfly Valve:

Nominal Diameter	D	D1	D2	L	H	n-Φd	L1	L2	Pneumatic Actuator No.
DN50	52.7	89	125	41.4	217	4*Φ16	150	72.5	AT-52
DN65	64.4	104	145	44	234	4*Φ16	171	83	AT-63
DN80	78.8	127	160	45	252	8*Φ16	186	95.5	AT-75
DN100	104.2	153	180	52	289	8*Φ16	206	103.5	AT-83
DN125	123.3	180	210	54	318	8*Φ16	265	108	AT-92
DN150	157	206	240	54	341	8*Φ20	272	121.5	AT-105
DN200	202.5	270	295	55	428	12*Φ20	304	142	AT-125
DN250	250.5	320	355	60	490	12*Φ24	395	151	AT-140
DN300	301.6	368	410	65	567	12*Φ24	462	174	AT-160
DN350	333.3	428	470	76			552	206	AT-190
DN400	389.6	482	525	86			556	226	AT-210
DN450	395.6	493	550	108			630	260	AT-240
DN500	491.6	605	585	130			630	260	AT-240

Different Material And Operation Of Lug Butterfly Valve:

Stainless Steel Wafer Pneumatic Actuator Valve Lug Type Single Acting EPDM 1

Butterfly Valve Operating Type Selection:

Stainless Steel Wafer Pneumatic Actuator Valve Lug Type Single Acting EPDM 2

Butterfly Valve Connection End Selection:

Butterfly Valve Disc Material Selection:

Butterfly Valve Seat Material Selection:

Seat Material Of Butterfly Valve:

Material Name	Description	Operating Temperature	Service Application
PTFE	Virgin PTFE is the most widely used sealing material with excellent characteristics suitable for most services. It has excellent chemical resistance throughout valve industries and low coefficient of frication	-20°F – 400°F -29°C – 205°C	General chemicals, low pressure services
RPTFE	RPTFE (Reinforced PTFE) is typically produced by adding 15% fiber glass to virgin PTFE. It has better pressure-temperature properties than virgin PTFE, better resistance to wear and deformation under load. Not to be used in hydrofluroic acid	-20°F – 400°F -29°C – 205°C	For low and medium pressure services
PCTFE	PCTFE is a homopolymer of chlorotrifluoroethylene, featuring high compressive strength and low deformation under load	-320°F – 248°F -196°C – 120°C	For low temperature low pressure services
Nylon	Nylon is a common seat material for Class 600 valves. It is highly resistance to many chemicals and abrasions, and can be used in air, oil and other gas media. It is not suitable for strong oxidization agents	-20°F – 176°F -29°C – 80°C	For high pressure, low temperature services
PPL	PPL (Polyparaphenylene) is an excellent seat material with low coefficient of friction, highly resistant to pressure and temperature	-50°F – 482°F -46°C – 250°C	For high temperature low pressure services
TFM	TFM (modified PTFE) is a chemically modified PTFE that offers enhanced properties while retaining all the proven advantages of a conventional PTFE	-112°F – 248°F -80°C – 120°C	For services requiring high purity
Metal	Metal (typically stellite) seats are used in severe conditions where flashing, hydraulic shock, abrasive media or trapped metal may exist in the line	-320°F – 1202°F -196°C – 650°C	For severe services

O-Ring Material Of Butterfly Valve:

Material Name	Description	Operating Temperature	Operating Pressure
NBR	Buna-N (NBR) is an all purpose polymer with good resistance to water, solvents, oil and hydraulic fluids	-50°F – 176°F -46°C – 80°C	Class 150 – 600 PN 20 – 100
HNBR	HNBR (Hydrogenated NBR) has similar media stability to NBR but with significantly better heat and oxidization stability	-67°F – 337°F -55°C – 170°C	Class 150 – 600 PN 20 – 100
Viton	Viton (fluorocarbon) is a fluorocarbon elastomer that is compatible with a broad range of chemicals. It performs well in mineral acids, salt solutions, chlorinated hydrocarbons and petroleum oils	-49°F – 320°F -22°C – 204°C	Class 150 – 600 PN 20 – 100
EPDM	EPDM has good abrasion and tear resistance with excellent chemical resistance to a variety of acids and alkalines. It is susceptible to attack by oil, strong acids and strong alkalines and should not be used in compressed air lines	-50°F – 302°F -46°C – 150°C	Class 150 – 600 PN 20 – 100

Matching Air Accessories Selection For Pneumatic Butterfly Valve:

Stainless Steel Wafer Pneumatic Actuator Valve Lug Type Single Acting EPDM 6

Pneumatic Actuator Accessories Options :

Pneumatic Actuator Accessories Options
Pneumatic Actuator Pisition	Applicable Connection Standard	Pneumatic Actuator Accessories
Actuator Upper	VDI/VDE 3845	● Limit Switch Box ● Proximity Switch ● P/P Pneumatic Positioner ( Control Input Signal Is 0.20-1.03 Bar or 3-15 PSI ) ● E/P Electro Pneumatic Positioner ( Control Input Signal Is 4-20mA )
Actuator Back	VDI/VDE 3845	Non Explosion-proof Type ExmbIICT4 / EX d IIB T6 / EX d IIC T6 / EX ia IIC T6 Explosion-proof Type ● 3/2 Way Namur Solenoid Valve ( For Spring Return Actuator ) ● 5/2 Way Namur Solenoid Valve ( For Double Acting Actuator ) Air Filter Regulator
Actuator Bottom	ISO5211/DIN3337	● Declutchable Gear Box ● Ball Valve , Butterfly Valve , Plug Valve

Single Acting & Double Acting Difference Of Pneumatic Actuator:

Principle Of Single Acting Pneumatic Actuator (Spring Return)
Counter - Clockwise	Clockwise

Air to port A forces the pistons outwards, causing the springs to compress, The pinion turns counterclockwise while air is being exhausted from port B. Loss of air pressure on port A, the stored energy in the springs forces the pistons inwards. The pinion turns clockwise while air is being exhausted from port A.	Air to port B forces the pistons outwards, causing the springs to compress, The pinion turns counterclockwise while air is being exhausted from port B. Loss of air pressure on port A, the stored energy in the springs forces the pistons inwards. The pinion turns clockwise while air is being exhausted from port A.

Principle Of Double Acting Pneumatic Actuator
Counter - Clockwise	Clockwise

Air to Port A forces the pistons outwards, causing the pinion to turn counterclockwise while the air is being exhausted from Port B. Air to Port B forces the pistons inwards, causing the pinion to turn clockwise while the air is being exhausted from Port A.	Air to Port A forces the pistons outwards, causing the pinion to turn clockwise while the air is being exhausted from Port B. Air to Port B forces the pistons inwards, causing the pinion to turn counterclockwise while the air is being exhausted from Port A.
